Contact Vinidex Customer Service for availability of products on this page.



Vinidex Code Nominal Diameter (mm) Effective Length (m) Overall Length (m) Approximate Pipe Mass (kg/length) Number of Pipes per Crate Semi Truck Load B-Double Truck Load
29520 225 5.96m 6.10m 19 12 144 216
29521 300 5.88m 6.05m 26 6 72 108
29522 375 5.79m 6.02m 47 4 or 6 60 90
29523 450 5.78m 6.00m 73 2 40 60
29524 525 5.69m 5.96m 100 2 32 48
29525 600 5.56m 5.90m 113 3 18 27

Product Support

Need some help? View our Product Support area for downloads, installations and jointing procedures.
