Contact Vinidex Customer Service for availability of products on this page.
Contact Vinidex Customer Service for availability of products on this page.
Vinidex Code | Size DN (SP x TH) | C | S | L |
34150 | 15x15 | 17.1 | 18 | 41.7 |
34160 | 20x15 | 17.1 | 18 | 42.1 |
34170 | 20x20 | 22.4 | 19.5 | 45.2 |
34190 | 25x20 | 22.4 | 19.5 | 46.4 |
34200 | 25x25 | 27.8 | 22.1 | 49.6 |
34230 | 32x25 | 27.8 | 22.1 | 54.8 |
34240 | 32x32 | 34.3 | 25.5 | 57.8 |
34260 | 40x20 | 22.4 | 19.5 | 54.7 |
34270 | 40x25 | 27.8 | 22.1 | 57.9 |
34280 | 40x32 | 34.3 | 25.5 | 60.9 |
34290 | 40x40 | 39.4 | 24.4 | 64.2 |
34320 | 50x25 | 27.8 | 22.1 | 61.1 |
34340 | 50x40 | 39.4 | 24.4 | 67.4 |
34350 | 50x50 | 49.5 | 29 | 67.4 |
34360* | 80x50 | 49.5 | 29.4 | 82.4 |
34370* | 80x80 | 83 | 35 | 160 |
34400* | 100x100 | 117 | 41.5 | 189 |
*These fittings are fabricated from other moulded fittings. |
